US14-US14 Bypass Corridor Study – Public Meeting #3

Virtual Public Information Meeting and Open House

Welcome to our US14-US14 Bypass Corridor Study virtual engagement! The South Dakota Department of Transportation (SDDOT) in conjunction with the City of Brookings and City of Volga are leading a study to develop a long range plan for the US14 and US14 Bypass corridors. Thank you for your participation in our online engagement.

The range of transportation improvement scenarios presented here are ready for public and stakeholder feedback. These scenarios group refined concepts presented at the previous public meeting and represent potential future projects to address long-term transportation needs. We appreciate your input.

How to Navigate

• Click the arrows on the right of your screen to go forward or the left to go backward. Use the navigation bar on the left side of your screen to revisit any part of the meeting.

Presentation Overview Video

Project Area Map

Segment Overview

Scenario A:
Maintain 2-Lane Highway with Intersection Improvements

• US14/US81 intersection improvements
• 458th Avenue intersection turn lanes
• 459th Avenue intersection turn lanes

Click the image above to enlarge.

Scenario B:
Maintain 2-Lane Highway with Passing Lanes and Intersection Improvements

• Two 1.5-mile westbound passing lane/multilane segments:
• 1.5 mile passing lane east of 459th Avenue
• Multilane highway extended approximately 1.5 miles west of Volga
• One eastbound passing lane and extension of US14 multilane west out of Volga:
• 1.5 mile passing lane east of 459th Avenue
• Multilane highway extended approximately 0.5 miles west of Volga
• US14/US81 intersection improvements
• 458th Avenue intersection turn lanes
• 459th Avenue intersection turn lanes

Click the image above to enlarge.

Scenario C:
Maintain 2-Lane Highway with Passing Lanes and Intersection Improvements

• Two 1.5-mile westbound passing lane/multilane segments:
• 1.5 mile passing lane east of 459th Avenue
• Multilane highway extended approximately 1.5 miles west of Volga
• One eastbound passing lane and extension of US14 multilane west out of Volga:
• 1.5 mile passing lane east of 459th Avenue
• Multilane highway extended approximately 0.5 miles west of Volga
• US14/US81 intersection improvements
• 458th Avenue intersection turn lanes
• 459th Avenue intersection turn lanes

Click the image above to enlarge.

Scenario D:
Multilane Divided Highway with Intersection Improvements

• Multilane divided highway between US81 intersection (existing multilane segment) and Volga (existing multilane segment).
• US14/US81 intersection improvements
• 458th Avenue intersection turn lanes
• 459th Avenue intersection turn lanes

Click the image above to enlarge.

US14/US81 Intersection Improvements

Layout reflects proposed 3.43-mil reconstruction project planned for 2023. This option is applicable with any of the four US14 – West of Volga corridor segment scenarios.

Click the image above to enlarge.

Preliminary Summary Matrix

Click the image above to enlarge.

Segment Overview

Scenario A:
Existing 5-Lane with Intersection Improvements

• Samara Avenue intersection improvements
• Maintain existing configuration at Kasan Avenue
• Hansina Avenue eastbound right turn lane
• Caspian Avenue intersection improvements

Click the image above to enlarge.

Scenario B:
Existing 5-Lane with Intersection Improvements

• Samara Avenue intersection improvements
• Extend multilane highway west out of Volga
• Maintain existing configuration at Kasan Avenue
• Hansina Avenue eastbound right turn lane
• Caspian Avenue intersection improvements

Click the image above to enlarge.

Scenario C:
Existing 5-Lane with Intersection Improvements

• Samara Avenue intersection improvements
• Extend two westbound lanes west out of Volga
• Add eastbound turn lanes
• Maintain existing configuration at Kasan Avenue
• Hansina Avenue eastbound right turn lane
• Caspian Avenue intersection improvements

Click the image above to enlarge.

Preliminary Summary Matrix

Click the image above to enlarge.

Segment Overview

Scenario A:
Existing 4-Lane Divided with Intersection Improvements

• Maintain existing 4-lane divided highway
• Add westbound right turn lane at 466th Avenue

Click the image above to enlarge.

Preliminary Summary Matrix

Click the image above to enlarge.

Segment Overview

Scenario B:
At-grade ‘T’ Intersection

• Removal of grade separated interchange
• Construct at-grade ‘T’ intersection to maximize spacing from 469th Avenue
• Two eastbound right-turn options: free or signalized

Click the image above to enlarge.

Scenario C(ii):
At-grade Intersection at 469th Avenue

• Removal of grade separated interchange
• Reroute US14 to 469th Avenue and construct 4-leg at-grade intersection
• Two eastbound right-turn options: free or signalized
• Rearage option shown north of US14 to remove access points within vicinity of the new intersection
• New connection between US14 and 469th Avenue south

Click the image above to enlarge.

Scenario C-iii (west):
At-grade Intersection with 469th Avenue Connection (west)

• Removal of grade separated interchange
• At-grade 4-leg intersection in vicinity of existing US14 alignment into Brookings
• Two eastbound right-turn options: free or signalized
• Tight east-west 469th Avenue north connection to minimize property impacts
• 469th Avenue (north) connection straight west from intersection
• Rearage option shown north of US14 to remove access points within vicinity of the new intersection

Click the image above to enlarge.

Scenario C-iii (north):
At-grade Intersection with 469th Avenue Connection (north)

• Removal of grade separated interchange
• At-grade 4-leg intersection in vicinity of existing US14 alignment into Brookings
• Two eastbound right-turn options: free or signalized
• 469th Avenue (north) connection sweeping north from intersection
• Rearage option shown north of US14 to remove access points within vicinity of the new intersection

Click the image above to enlarge.

Preliminary Summary Matrix

Click the image above to enlarge.

Segment Overview

Scenario A:
Existing 3-Lane with Intersection Improvements

• Corridor: Maintain one through lane in each direction
• Shared-use path on south side of US14 Bypass
• Western Avenue intersection improvements
• Medary Avenue intersection improvements
• Stadium Road and Jackrabbit Avenue intersection improvements
• Both maintained as full access intersections
• 22nd Avenue intersection improvements
• Frontage roads in NW and NE quadrants to remove access from intersection area
• 25th Avenue intersection improvements

Click the image above to enlarge.

Scenario B:
Multilane Hybrid (4-Lane Divided and 5-Lane) with Intersection Improvements

• Corridor: two through lanes in each direction with combination of 4-lane divided and 5-lane sections
• Shared-use path on south side of US14 Bypass
• Western Avenue intersection improvements
• Medary Avenue intersection improvements
• Stadium Road and Jackrabbit Avenue intersection improvements
• Stadium Road ¾ access; Jackrabbit Avenue full access
• 22nd Avenue intersection improvements
• Frontage roads in NW and NE quadrants to remove access from intersection area
• 25th Avenue intersection improvements

Click the image above to enlarge.

Scenario C:
4-Lane Divided with Intersection Improvements

• Corridor: two through lanes in each direction with a 4-lane divided (raised median) section
• Shared-use path on south side of US14 Bypass
• Western Avenue intersection improvements
• Medary Avenue intersection improvements
• Stadium Road and Jackrabbit Avenue intersection improvements
• Stadium Road ¾ access; Jackrabbit Avenue full access
• 22nd Avenue intersection improvements
• Shift US14 Bypass alignment south
• Frontage roads in NW and NE quadrants to remove access from intersection area
• 25th Avenue intersection improvements

Click the image above to enlarge.

Preliminary Summary Matrix

Click the image above to enlarge.

Segment Overview

Scenario A:
Maintain Existing Bridge with Ramp Terminal Improvements

• Maintains existing 2-lane bridge
• No bridge widening; does not accommodate shared-use path across I-29
• Ramp terminal intersection improvements at existing locations
• Two options to tie into US14 Bypass corridor beyond ramp terminals:
• Option A: ramp terminal intersections tie into existing 3-lane corridor
• Option B: ramp terminal intersections tie into a potential 4-Lane divided corridor

Click the image above to enlarge.

Scenario B:
3-Lane Cross-Section across Bridge with Ramp Terminal Improvements

• US14 Bypass reconstruction through interchange as a 3-lane section (one through lane in each direction)
• New bridge
• Northbound ramp terminal shifted west to increase spacing with 32nd Avenue intersection
• Ramp terminal intersection improvements
• Two options to tie into US14 Bypass corridor beyond ramp terminals:
• Option A: ramp terminal intersections tie into existing 3-lane corridor
• Option B: ramp terminal intersections tie into a potential 4-Lane divided corridor
• Shared-use path on south side

Click the image above to enlarge.

Scenario C:
Multilane Cross-Section across Bridge with Ramp Terminal Improvements

• US14 Bypass reconstruction through interchange as a 4-lane dived section (two through lanes in each direction)
• New bridge
• Northbound ramp terminal shifted west to increase spacing with 32nd Avenue intersection
• Ramp terminal intersection improvements
• Shared-use path on south side

Click the image above to enlarge.

Preliminary Summary Matrix

Click the image above to enlarge.

Segment Overview

Scenario A:
Existing 3-Lane with Intersection Improvements

• Maintain existing 3-lane between 32nd Avenue and 34th Avenue
• Maintain existing 2-lane between 34th Avenue and US14 (east)
• 32nd Avenue intersection improvements
• 34th Avenue intersection improvements
• US14/US14 Bypass intersection (east) improvements (three options)
• 211th Street/18th Street intersection improvements (two options)
• Shared-use path on south side

Click the image above to enlarge.

Scenario B:
Existing 3-Lane with Intersection Improvements

• 4-lane divided between 32nd Avenue and 34th Avenue
• Maintain existing 2-lane between 34th Avenue and US14 (east) (similar to Scenario A)
• 32nd Avenue intersection improvements
• 34th Avenue intersection improvements
• US14/US14 Bypass intersection (east) improvements (three options)
• 211th Street/18th Street intersection improvements (two options)
• Shared-use path on south side

Click the image above to enlarge.

211th Street/18th Street Intersection Options

• Option A. Realign 211th Street/18th Street to provide 250 feet separation from US14 Bypass
• Option B. Realign 211th Street/18th Street to create intersection US14 Bypass ¼ mile east of 34th Avenue

Click the image above to enlarge.

US14/US14 Bypass (east) Intersection Options

• Option A. Intersection improvements (existing configuration)
• Option B. Intersection improvements (free right turn)
• Option C. Intersection improvements (urban intersection, all movements at main intersection)

All options include an acceleration lane for southbound to eastbound left turn movements.

Click the image above to enlarge.

Preliminary Summary Matrix

Click the image above to enlarge.

Plan Overview

The Bicycle and Pedestrian Plan presents a long-range plan for bicycle and pedestrian facilities along the urban and developing areas of the US14-US14 Bypass corridor. This plan will serve as a guide for incorporating shared-use path facilities in future projects and promoting a continuous and connected network.

• In Volga: continuous shared-use path on the north side of US14 with future crossing locations.

• Volga to Brookings: route options to provide a shared-use path between Volga and Brookings.

• US14 Bypass: continuous shared-use path on the south side of US14 Bypass with potential connections to existing and planned City of Brookings and SDSU bicycle and pedestrian facilities.

Click the image above to enlarge.

Plan Overview

The ITS Plan presents potential ITS technologies and deployment locations for consideration as part of improvements to the US14-US14 Bypass corridor. This plan can be used as a guide to implement these technologies as part of future corridor projects and/or SDDOT statewide ITS programs.

Click the image above to enlarge.

Plan Overview

The Blowing Snow Plan identifies potential locations for snow fence at problematic blowing snow areas identified by the study team, SDDOT maintenance staff, the public, and study stakeholders along the US14-US14 Bypass corridor. This plan will serve as a guide for implementation of snow fences as well as incorporation of blowing snow measures into design as part of future corridor projects.

Click the image above to enlarge.

Project Schedule

Review the high-level schedule below to see how the project has progressed. Final reports are tentatively scheduled for delivery in September 2020.

Click the image above to enlarge.

Level of Service Definitions

Level of service (LOS) is a quantitative stratification of performance measures representing quality of service, or how well a transportation facility operates from a traveler’s perspective.

Click the image above to enlarge.

Tell Us What You Think

Input collected will aid in the development of study recommendations and general timeline for implementation.

• Questions and comments will be accepted until August 21st, 2020 and may be submitted through the study website or by reaching out to one of the project representatives via email or phone.
